Exposing Swagger UI is a good way to help developers consume your APIs. But don’t be boring: customize your UI with some fancy CSS
Table of Contents
Just a second! 🫷 If you are here, it means that you are a software developer.
So, you know that storage, networking, and domain management have a cost .
If you want to support this blog, please ensure that you have disabled the adblocker for this site. I configured Google AdSense to show as few ADS as possible – I don’t want to bother you with lots of ads, but I still need to add some to pay for the resources for my site.
Thank you for your understanding. – Davide
Brace yourself, Christmas is coming! 🎅
If you want to add a more festive look to your Swagger UI, it’s just a matter of creating a CSS file and injecting it.
You should create a custom CSS for your Swagger endpoints, especially if you are exposing them outside your company: if your company has a recognizable color palette, using it in your Swagger pages can make your brand stand out.
In this article, we will learn how to inject a CSS file in the Swagger UI generated using .NET Minimal APIs.
How to add Swagger in your .NET Minimal APIs
There are plenty of tutorials about how to add Swagger to your APIs. I wrote some too, where I explained how every configuration impacts what you see in the UI.
That article was targeting older dotNET versions without Minimal APIs. Now everything’s easier.
When you create your API project, Visual Studio asks you if you want to add OpenAPI support (aka Swagger). By adding it, you will have everything in place to get started with Swagger.
The key parts are builder.Services.AddEndpointsApiExplorer(), builder.Services.AddSwaggerGen(), app.UseSwagger(), app.UseSwaggerUI() and WithOpenApi(). Do you know that those methods do? If so, drop a comment below! 📩
Now, if we run our application, we will see a UI similar to the one below.
That’s a basic UI. Quite boring, uh? Let’s add some style
Create the CSS file for Swagger theming
All the static assets must be stored within the wwwroot folder. It does not exist by default, so you have to create it manually. Click on the API project, add a new folder, and name it “wwwroot”. Since it’s a special folder, by default Visual Studio will show it with a special icon (it’s a sort of blue world, similar to 🌐).
Now you can add all the folders and static resources needed.
I’ve created a single CSS file under /wwwroot/assets/css/xmas-style.css. Of course, name it as you wish – as long as it is within the wwwroot folder, it’s fine.
the element selectors are taken directly from the Swagger UI – you’ll need a bit of reverse-engineering skills: just open the Browser Console and find the elements you want to update;
unless the element does not already have the rule you want to apply, you have to add the !important CSS operator. Otherwise, your code won’t affect the UI;
you can add assets from other folders: I’ve added background-image: url("../images/snowflakes.webp"); to the body style. That image is, as you can imagine, under the wwwroot folder we created before.
Just as a recap, here’s my project structure:
Of course, it’s not enough: we have to tell Swagger to take into consideration that file
How to inject a CSS file in Swagger UI
This part is quite simple: you have to update the UseSwaggerUI command within the Main method:
CSS is not the only part you can customize, there’s way more. Here’s an article I wrote about Swagger integration in .NET Core 3 APIs, but it’s still relevant (I hope! 😁)
Theming is often not considered an important part of API development. That’s generally correct: why should I bother adding some fancy colors to APIs that are not expected to have a UI?
This makes sense if you’re working on private APIs. In fact, theming is often useful to improve brand recognition for public-facing APIs.
You should also consider using theming when deploying APIs to different environments: maybe Blue for Development, Yellow for Staging, and Green for Production. That way your developers can understand which environment they’re exploring right easily.
User experience relies on small, thoughtful details that fit well into the overall design without overpowering the user. This balance can be tricky, especially with technologies like WebGL. While they can create amazing visuals, they can also become too complicated and distracting if not handled carefully.
One subtle but effective technique is the Bayer Dithering Pattern. For example, JetBrains’ recent Junie campaign page uses this approach to craft an immersive and engaging atmosphere that remains visually balanced and accessible.
In this tutorial, I’ll introduce you to the Bayer Dithering Pattern. I’ll explain what it is, how it works, and how you can apply it to your own web projects to enhance visual depth without overpowering the user experience.
Bayer Dithering
The Bayer pattern is a type of ordered dithering, which lets you simulate gradients and depth using a fixed matrix.
If we scale this matrix appropriately, we can target specific values and create basic patterns.
Here’s a simple example:
// 2×2 Bayer matrix pattern: returns a value in [0, 1)
float Bayer2(vec2 a)
{
a = floor(a); // Use integer cell coordinates
return fract(a.x / 2.0 + a.y * a.y * 0.75);
// Equivalent lookup table:
// (0,0) → 0.0, (1,0) → 0.5
// (0,1) → 0.75, (1,1) → 0.25
}
Let’s walk through an example of how this can be used:
// 1. Base mask: left half is a black-to-white gradient
float mask = uv.y;
// 2. Right half: apply ordered dithering
if (uv.x > 0.5) {
float dither = Bayer2(fragCoord);
mask += dither - 0.5;
mask = step(0.5, mask); // binary threshold
}
// 3. Output the result
fragColor = vec4(vec3(mask), 1.0);
So with just a small matrix, we get four distinct dithering values—essentially for free.
See the Pen
Bayer2x2 by zavalit (@zavalit)
on CodePen.
Creating a Background Effect
This is still pretty basic—nothing too exciting UX-wise yet. Let’s take it further by creating a grid on our UV map. We’ll define the size of a “pixel” and the size of the matrix that determines whether each “pixel” is on or off using Bayer ordering.
You’ll see a rendered UV grid with blue dots for pixels and white (and subsequent blocks of the same size) for the Bayer matrix.
See the Pen
Pixel & Cell UV by zavalit (@zavalit)
on CodePen.
Recursive Bayer Matrices
Bayer’s genius was a recursively generated mask that keeps noise high-frequency and code low-complexity. So now let’s try it out, and apply also larger dithering matrix:
This gives us a nice visual transition from a basic UV grid to Bayer matrices of increasing complexity (2×2, 4×4, 8×8, 16×16).
See the Pen
Bayer Ranges Animation by zavalit (@zavalit)
on CodePen.
As you see, the 8×8 and 16×16 patterns are quite similar—beyond 8×8, the perceptual gain becomes minimal. So we’ll stick with Bayer8 for the next step.
Now, we’ll apply Bayer8 to a UV map modulated by fbm noise to make the result feel more organic—just as we promised.
See the Pen
Bayer fbm noise by zavalit (@zavalit)
on CodePen.
Adding Interactivity
Here’s where things get exciting: real-time interactivity that background videos can’t replicate. Let’s run a ripple effect around clicked points using the dithering pattern. We’ll iterate over all active clicks and compute a wave:
See the Pen
Untitled by zavalit (@zavalit)
on CodePen.
Final Thoughts
Because the entire Bayer-dither background is generated in a single GPU pass, it renders in under 0.2 ms even at 4K, ships in ~3 KB (+ Three.js in this case), and consumes zero network bandwidth after load. SVG can’t touch that once you have thousands of nodes, and autoplay video is two orders of magnitude heavier on bandwidth, CPU and battery. In short: this is the probably one of the lightest fully-interactive background effect you can build on the open web today.
A zero-day attack is defined as a cyber attack that happens when the vendor is unaware of any flaw or security vulnerability in the software, hardware, or firmware. The unknown or unaddressed vulnerability used in a zero-day attack is called a zero-day vulnerability.
What makes a Zero Day Attack lethal for organizations is
-They are often targeted attacks before the vendor can release the fix for the security vulnerability
– The malicious actor uses a zero-day exploit to plant malware, steal data, or exploit the users, organizations, or systems as part of cyber espionage or warfare.
– They take days to contain, as the fix is yet to be released by the vendors
Examples of Zero-Day Attacks in 2025
As per the India Cyber Threat Report 2025, these are the top zero day attacks identified in 2024, detailing their nature, potential impacts, and associated CVE identifiers.
A severe remote command execution vulnerability that allows attackers to execute unauthorized shell commands due to improper input validation. While authentication is typically required, an associated authentication flaw enables attackers to bypass this requirement, facilitating full system compromise.
Microsoft Windows Shortcut Handler (CVE-2024-21412)
A critical security bypass vulnerability in Windows’ shortcut file processing. It enables remote code execution through specially crafted shortcut (.lnk) files, circumventing established security controls when users interact with these malicious shortcuts.
This Server-Side request forgery vulnerability in the SAML component allows attackers to initiate unauthorized requests through the application. Successful exploitation grants access to internal network resources and enables the forwarding of malicious requests, leading to broader network compromise.
Mozilla Firefox Animation Timeline Use-After-Free (CVE-2024-9680)
A use-after-free vulnerability in Firefox’s animation timeline component permits remote code execution when users visit specially crafted websites. This vulnerability can lead to full system compromise, posing significant security risks to users.
How a Zero-day Attack Works?
Step 1: A software code creates a vulnerability without the developer realizing it.
Step 2: A malicious actor discovers this vulnerability and launches a targeted attack to exploit the code.
Step 3: The developer reliazes a security vulnerability in the software yet does not have a patch ready to fix it.
Step 4: The developers release a security patch to close the security vulnerability.
Step 5: The developers deploy the security patch.
The gap between the zero-day attack and the developers deploying a security patch is enough for a successful attack and may lead to a ransomware demand, system infiltration, and sensitive data leak. So how do we protect against
LINQ is a set of methods that help developers perform operations on sets of items. There are tons of methods – do you know which is the one for you?
Table of Contents
Just a second! 🫷 If you are here, it means that you are a software developer.
So, you know that storage, networking, and domain management have a cost .
If you want to support this blog, please ensure that you have disabled the adblocker for this site. I configured Google AdSense to show as few ADS as possible – I don’t want to bother you with lots of ads, but I still need to add some to pay for the resources for my site.
Thank you for your understanding. – Davide
LINQ is one of the most loved functionalities by C# developers. It allows you to perform calculations and projections over a collection of items, making your code easy to build and, even more, easy to understand.
As of C# 11, there are tens of methods and overloads you can choose from. Some of them seem similar, but there are some differences that might not be obvious to C# beginners.
In this article, we’re gonna learn the differences between couples of methods, so that you can choose the best one that fits your needs.
First vs FirstOrDefault
Both First and FirstOrDefault allow you to get the first item of a collection that matches some requisites passed as a parameter, usually with a Lambda expression:
int[] numbers = newint[] { -2, 1, 6, 12 };
var mod3OrDefault = numbers.FirstOrDefault(n => n % 3 == 0);
var mod3 = numbers.First(n => n % 3 == 0);
Using FirstOrDefault you get the first item that matches the condition. If no items are found you’ll get the default value for that type. The default value depends on the data type:
Data type
Default value
int
0
string
null
bool
false
object
null
To know the default value for a specific type, just run default(string).
So, coming back to FirstOrDefault, we have these two possible outcomes:
On the other hand, First throws an InvalidOperationException with the message “Sequence contains no matching element” if no items in the collection match the filter criterion:
While First returns the first item that satisfies the condition, even if there are more than two or more, Single ensures that no more than one item matches that condition.
If there are two or more items that passing the filter, an InvalidOperationException is thrown with the message “Sequence contains more than one matching element”.
int[] numbers = newint[] { -2, 1, 6, 12 };
numbers.First(n => n % 3 == 0); // 6numbers.Single(n => n % 3 == 0); // throws exception because both 6 and 12 are accepted values
Both methods have their corresponding -OrDefault counterpart: SingleOrDefault returns the default value if no items are valid.
int[] numbers = newint[] { -2, 1, 6, 12 };
numbers.SingleOrDefault(n => n % 4 == 0); // 12numbers.SingleOrDefault(n => n % 7 == 0); // 0, because no items are %7numbers.SingleOrDefault(n => n % 3 == 0); // throws exception
Any vs Count
Both Any and Count give you indications about the presence or absence of items for which the specified predicate returns True.
In this article, we learned the differences between couples of LINQ methods.
Each of them has a purpose, and you should use the right one for each case.
❓ A question for you: talking about performance, which is more efficient: First or Single? And what about Count() == 0 vs Any()? Drop a message below if you know the answer! 📩
I hope you enjoyed this article! Let’s keep in touch on Twitter or on LinkedIn, if you want! 🤜🤛
For months, Eduard Bodak has been sharing glimpses of his visually rich new website. Now, he’s pulling back the curtain to walk us through how three of its most striking animations were built. In this behind-the-scenes look, he shares the reasoning, technical decisions, and lessons learned—from performance trade-offs to working with CSS variables and a custom JavaScript architecture.
Overview
In this breakdown, I’ll walk you through three of the core GSAP animations on my site: flipping 3D cards that animate on scroll, an interactive card that reacts to mouse movement on the pricing page, and a circular layout of cards that subtly rotates as you scroll. I’ll share how I built each one, why I made certain decisions, and what I learned along the way.
Overview of the animations we’re handling here
I’m using Locomotive Scroll V5 in this project to handle scroll progress and viewport detection. Since it already offers built-in progress tracking via data attributes and CSS variables, I chose to use that directly for triggering animations. ScrollTrigger offers a lot of similar functionality in a more integrated way, but for this build, I wanted to keep everything centered around Locomotive’s scroll system to avoid overlap between two scroll-handling libraries.
Personally, I love the simplicity of Locomotive Scroll. You can just add data attributes to specify the trigger offset of the element within the viewport. You can also get a CSS variable --progress on the element through data attributes. This variable represents the current progress of the element and ranges between 0 and 1. This alone can animate a lot with just CSS.
I used this project to shift my focus toward more animations and visual details. It taught me a lot about GSAP, CSS, and how to adjust animations based on what feels right. I’ve always wanted to build sites that spark a little emotion when people visit them.
Note that this setup was tailored to the specific needs of the project, but in cases where scroll behavior, animations, and state management need to be tightly integrated, GSAP’s ScrollTrigger and ScrollSmoother can offer a more unified foundation.
Now, let’s take a closer look at the three animations in action!
Flipping 3D cards on scroll
I split the animation into two parts. The first is about the cards escaping on scroll. The second is about them coming back and flipping back.
While I’m using Locomotive Scroll, I need data-scroll to enable viewport detection on an element. data-scroll-offset specifies the trigger offset of the element within the viewport. It takes two values: one for the offset when the element enters the viewport, and a second for the offset when the element leaves the viewport. The same can be built with GSAP’s ScrollTrigger, just inside the JS.
data-scroll-event-progress="progressHero" will trigger the custom event I defined here. This event allows you to retrieve the current progress of the element, which ranges between 0 and 1.
Inside the JS we can add an EventListener based on the custom event we defined. Getting the progress from it and transfer it to the GSAP timeline.
this.element is here our section we defined before, so it’s data-hero-animation.
Building now the timeline method inside the class. Getting the current timeline progress. Killing the old timeline and clearing any GSAP-applied inline styles (like transforms, opacity, etc.) to avoid residue.
Using requestAnimationFrame() to avoid layout thrashing. Initializes a new, paused GSAP timeline. While we are using Locomotive Scroll it’s important that we pause the timeline, so the progress of Locomotive can handle the animation.
Figuring out relative positioning per card. targetY moves each card down so it ends near the bottom of the container. yOffsets and rotationZValues give each card a unique vertical offset and rotation.
The actual GSAP timeline. Cards slide left or right based on their index (x). Rotate on Z slightly to look scattered. Slide downward (y) to target position. Shrink and tilt (scale, rotateX) for a 3D feel. index * 0.012: adds a subtle stagger between cards.
That’s our timeline for desktop. We can now set up GSAP’s matchMedia() to use it. We can also create different timelines based on the viewport. For example, to adjust the animation on mobile, where such an immersive effect wouldn’t work as well. Even for users who prefer reduced motion, the animation could simply move the cards slightly down and fade them out, as you can see on the live site.
Add this to our init() method to initialize the class when we call it.
init() {
this.setupBreakpoints();
}
We can also add a div with a background color on top of the card and animate its opacity on scroll so it smoothly disappears.
When you look closely, the cards are floating a bit. To achieve that, we can add a repeating animation to the cards. It’s important to animate yPercent here, because we already animated y earlier, so there won’t be any conflicts.
gsap.utils.random(1.5, 2.5) comes in handy to make each floating animation a bit different, so it looks more natural. repeatRefresh: true lets the duration refresh on every repeat.
Part 02
We basically have the same structure as before. Only now we’re using a sticky container. The service_container has height: 350vh, and the service_sticky has min-height: 100vh. That’s our space to play the animation.
In the JS, we can use the progressService event as before to get our Locomotive Scroll progress. We just have another timeline here. I’m using keyframes to really fine-tune the animation.
const position = 2 - index - 1 changes the position, so cards start spread out: right, center, left. With that we can use those arrays [12, 0, -12] in the right order.
There’s the same setupBreakpoints() method as before, so we actually just need to change the timeline animation and can use the same setup as before, only in a new JS class.
We can add the same floating animation we used in part 01, and then we have the disappearing/appearing card effect.
Part 2.1
Another micro detail in that animation is the small progress preview of the three cards in the top right.
We add data-scroll-css-progress to the previous section to get a CSS variable --progress ranging from 0 to 1, which can be used for dynamic CSS effects. This data attribute comes from Locomotive Scroll.
Using CSS calc() with min() and max() to trigger animations at specific progress points. In this case, the first animation starts at 0% and finishes at 33%, the second starts at 33% and finishes at 66%, and the last starts at 66% and finishes at 100%.
On a closer look, you can see a small slide-in animation of the card before the mouse movement takes effect. This is built in GSAP using the onComplete() callback in the timeline. this.card refers to the element with data-price-card.
I’m using an elastic easing that I got from GSAPs Ease Visualizer. The timeline plays when the page loads and triggers the mouse movement animation once complete.
In our initAnimation() method, we can use GSAP’s matchMedia() to enable the mouse movement only when hover and mouse input are available.
this.mm = gsap.matchMedia();
initAnimation() {
this.mm.add("(hover: hover) and (pointer: fine) and (prefers-reduced-motion: no-preference)", () => {
gsap.ticker.add(this.mouseMovement);
return () => {
gsap.ticker.remove(this.mouseMovement);
};
});
this.mm.add("(hover: none) and (pointer: coarse) and (prefers-reduced-motion: no-preference)", () => {
...
});
}
By using the media queries hover: hover and pointer: fine, we target only devices that support a mouse and hover. With prefers-reduced-motion: no-preference, we add this animation only when reduced motion is not enabled, making it more accessible. For touch devices or smartphones, we can use hover: none and pointer: coarse to apply a different animation.
I’m using gsap.ticker to run the method this.mouseMovement, which contains the logic for handling the rotation animation.
I originally started with one of the free resources from Osmo (mouse follower) and built this mouse movement animation on top of it. I simplified it to only use the mouse’s x position, which was all I needed.
I also added calculations for how much the card can rotate on the y-axis, and it rotates the z-axis accordingly. That’s how we get this mouse movement animation.
When building these animations, there are always some edge cases I didn’t consider before. For example, what happens when I move my mouse outside the window? Or if I hover over a link or button, should the rotation animation still play?
I added behavior so that when the mouse moves outside, the card rotates back to its original position. The same behavior applies when the mouse leaves the hero section or hovers over navigation elements.
I added a state flag this.isHovering. At the start of mouseMovement(), we check if this.isHovering is false, and if so, return early. The onMouseLeave method rotates the card back to its original position.
We can adjust it further by adding another animation for mobile, since there’s no mouse movement there. Or a subtle reflection effect on the card like in the video. This is done by duplicating the card, adding an overlay with a gradient and backdrop-filter, and animating it similarly to the original card, but with opposite values.
Cards in a circular position that slightly rotate on scroll
First, we build the base of the circularly positioned cards in CSS.
At first, we add all 24 cards, then remove the ones we don’t want to show later because we don’t see them. In the CSS, the .wheel uses a grid display, so we apply grid-area: 1 / 1 to stack the cards. We later add an overlay before the wheel with the same grid-area. By using em we can use a fluid font-size to adjust the size pretty smooth on resizing the viewport.
We can remove the card from 8 to 19 as we don’t see them behind the overlay. It should look like this now.
By adding the data attributes and setup for viewport detection from Locomotive Scroll, which we used in previous modules, we can simply add our GSAP timeline for the rotation animation.
There are probably smarter ways to build these animations than I used. But since this is my first site after changing my direction and GSAP, Locomotive Scroll V5, Swup.js, and CSS animations, I’m pretty happy with the result. This project became a personal playground for learning, it really shows that you learn best by building what you imagine. I don’t know how many times I refactored my code along the way, but it gave me a good understanding of creating accessible animations.
I also did a lot of other animations on the site, mostly using CSS animations combined with JavaScript for the logic behind them.
There are also so many great resources out there to learn GSAP and CSS.
Where I learned the most:
It’s all about how you use it. You can copy and paste, which is fast but doesn’t help you learn much. Or you can build on it your own way and make it yours, that’s at least what helped me learn the most in the end.
Why buy a whole tool when you can build your own? Learn how the Type system works in .NET, and create your own minimal type analyser.
Table of Contents
Just a second! 🫷 If you are here, it means that you are a software developer.
So, you know that storage, networking, and domain management have a cost .
If you want to support this blog, please ensure that you have disabled the adblocker for this site. I configured Google AdSense to show as few ADS as possible – I don’t want to bother you with lots of ads, but I still need to add some to pay for the resources for my site.
Thank you for your understanding. – Davide
Analysing your code is helpful to get an idea of the overall quality. At the same time, having an automatic tool that identifies determinate characteristics or performs some analysis for you can be useful.
Sure, there are many fantastic tools available, but having a utility class that you can build as needed and run without setting up a complex infrastructure is sufficient.
In this article, we are going to see how to navigate assemblies, classes, methods and parameters to perfor some custom analysis.
For this article, my code is structured into 3 Assemblies:
CommonClasses, a Class Library that contains some utility classes;
NetCoreScripts, a Class Library that contains the code we are going to execute;
ScriptsRunner, a Console Application that runs the scripts defined in the NetCoreScripts library.
The dependencies between the modules are shown below: ScriptsRunner depends on NetCoreScripts, and NetCoreScripts depends on CommonClasses.
In this article, we are going to write the examples in the NetCoreScripts class library, in a class named AssemblyAnalysis.
How to load an Assembly in C#, with different methods
The starting point to analyse an Assembly is, well, to have an Assembly.
So, in the Scripts Class Library (the middle one), I wrote:
var assembly = DefineAssembly();
In the DefineAssembly method we can choose the Assembly we are going to analyse.
In short, you can access the Assembly info of whichever class you know – if you can reference it directly, of course!
Load the current, the calling, and the executing Assembly
The Assembly class provides you with some methods that may look similar, but give you totally different info depending on how your code is structured.
Remember the ScriptsRunner –> NetCoreScripts –> CommonClasses sequence? To better explain how things work, let’s run the following examples in a method in the CommonClasses class library (the last one in the dependency chain).
var executing = System.Reflection.Assembly.GetExecutingAssembly();
var calling = System.Reflection.Assembly.GetCallingAssembly();
var entry = System.Reflection.Assembly.GetEntryAssembly();
Assembly.GetExecutingAssembly returns the Assembly that contains the actual code instructions (so, in short, the Assembly that actually contains the code). In this case, it’s the CommonClasses Assembly.
Assembly.GetCallingAssembly returns the caller Assembly, so the one that references the Executing Assembly. In this case, given that the CommonClasses library is referenced only by the NetCoreScripts library, well, we are getting info about the NetCoreScripts class library.
Assembly.GetEntryAssembly returns the info of the Assembly that is executing the whole application – so, the entry point. In our case, it’s the ScriptsRunner Console Application.
Deciding which one to choose is crucial, especially when you are going to distribute your libraries, for example, as NuGet packages. For sure, you’ll know the Executing Assembly. Most probably, depending on how the project is structured, you’ll also know the Calling Assembly. But almost certainly you won’t know the Entry Assembly.
Method name
Meaning
In this example…
GetExecutingAssembly
The current Assembly
CommonClasses
GetCallingAssembly
The caller Assembly
NetCoreScripts
GetEntryAssembly
The top-level executor
ScriptsRunner
How to retrieve classes of a given .NET Assembly
Now you have an Assembly to analyse. It’s time to load the classes belonging to your Assembly.
You can start with assembly.GetTypes(): this method returns all the types (in the form of a Type array) belonging to the Assembly.
For each Type you can access several properties, such as IsClass, IsPublic, IsAbstract, IsGenericType, IsEnum and so on. The full list of properties of a Type is available 🔗here.
You may want to analyse public classes: therefore, you can do something like:
If we have a look at its parameters, we will find the following values:
Bonus tip: Auto-properties act as Methods
Let’s focus a bit more on the properties of a class.
Consider this class:
publicclassUser{
publicstring Name { get; set; }
}
There are no methods; only one public property.
But hey! It turns out that properties, under the hood, are treated as methods. In fact, you can find two methods, named get_Name and set_Name, that act as an access point to the Name property.
Further readings
Do you remember that exceptions are, in the end, Types?
And that, in the catch block, you can filter for exceptions of a specific type or with a specific condition?
From here, you can use all this info to build whatever you want. Personally, I used it to analyse my current project, checking how many methods accept more than N parameters as input, and which classes have the highest number of public methods.
In short, an example of a simple code analyser can be this one:
publicvoid Execute()
{
var assembly = DefineAssembly();
var paramsInfo = AnalyzeAssembly(assembly);
AnalyzeParameters(paramsInfo);
}
privatestatic Assembly DefineAssembly()
=> Assembly.GetExecutingAssembly();
publicstatic List<ParamsMethodInfo> AnalyzeAssembly(Assembly assembly)
{
List<ParamsMethodInfo> all = new List<ParamsMethodInfo>();
var types = GetAllPublicTypes(assembly);
foreach (var type in types)
{
var publicMethods = GetPublicMethods(type);
foreach (var method in publicMethods)
{
var parameters = method.GetParameters();
if (parameters.Length > 0)
{
var f = parameters.First();
}
all.Add(new ParamsMethodInfo(
assembly.GetName().Name,
type.Name,
method
));
}
}
return all;
}
privatestatic MethodInfo[] GetPublicMethods(Type type) =>
type.GetMethods(BindingFlags.Instance | BindingFlags.Static | BindingFlags.Public | BindingFlags.DeclaredOnly);
privatestatic List<Type> GetAllPublicTypes(Assembly assembly) => assembly.GetTypes()
.Where(t => t.IsClass && t.IsPublic)
.ToList();
publicclassParamsMethodInfo(string AssemblyName, string ClassName, MethodInfo Method)
{
publicstring MethodName => Method.Name;
public ParameterInfo[] Parameters => Method.GetParameters();
}
And then, in the AnalyzeParameters, you can add your own logic.
As you can see, you don’t need to adopt complex tools to perform operations like this: just knowing that you can access the static details of each class and method can be enough (of course, it depends on the use!).
I hope you enjoyed this article! Let’s keep in touch on LinkedIn, Twitter or BlueSky! 🤜🤛
Back in November 2024, I shared a post on X about a tool I was building to help visualize kitchen remodels. The response from the Three.js community was overwhelmingly positive. The demo showed how procedural rendering techniques—often used in games—can be applied to real-world use cases like designing and rendering an entire kitchen in under 60 seconds.
In this article, I’ll walk through the process and thinking behind building this kind of procedural 3D kitchen design tool using vanilla Three.js and TypeScript—from drawing walls and defining cabinet segments to auto-generating full kitchen layouts. Along the way, I’ll share key technical choices, lessons learned, and ideas for where this could evolve next.
Have been wanting to redesign my parents’ kitchen for a while now
…so I built them a little 3D kitchen design-tool with @threejs, so they can quickly prototype floorplans/ideas
Here’s me designing a full kitchen remodel in ~60s 🙂
You can try out an interactive demo of the latest version here: https://kitchen-designer-demo.vercel.app/. (Tip: Press the “/” key to toggle between 2D and 3D views.)
Designing Room Layouts with Walls
Example of user drawing a simple room shape using the built-in wall module.
To initiate our project, we begin with the wall drawing module. At a high level, this is akin to Figma’s pen tool, where the user can add one line segment at a time until a closed—or open-ended—polygon is complete on an infinite 2D canvas. In our build, each line segment represents a single wall as a 2D plane from coordinate A to coordinate B, while the complete polygon outlines the perimeter envelope of a room.
We begin by capturing the [X, Z] coordinates (with Y oriented upwards) of the user’s initial click on the infinite floor plane. This 2D point is obtained via Three.js’s built-in raycaster for intersection detection, establishing Point A.
As the user hovers the cursor over a new spot on the floor, we apply the same intersection logic to determine a temporary Point B. During this movement, a preview line segment appears, connecting the fixed Point A to the dynamic Point B for visual feedback.
Upon the user’s second click to confirm Point B, we append the line segment (defined by Points A and B) to an array of segments. The former Point B instantly becomes the new Point A, allowing us to continue the drawing process with additional line segments.
Here is a simplified code snippet demonstrating a basic 2D pen-draw tool using Three.js:
import * as THREE from 'three';
const scene = new THREE.Scene();
const camera = new THREE.PerspectiveCamera(75, window.innerWidth / window.innerHeight, 0.1, 1000);
camera.position.set(0, 5, 10); // Position camera above the floor looking down
camera.lookAt(0, 0, 0);
const renderer = new THREE.WebGLRenderer();
renderer.setSize(window.innerWidth, window.innerHeight);
document.body.appendChild(renderer.domElement);
// Create an infinite floor plane for raycasting
const floorGeometry = new THREE.PlaneGeometry(100, 100);
const floorMaterial = new THREE.MeshBasicMaterial({ color: 0xcccccc, side: THREE.DoubleSide });
const floor = new THREE.Mesh(floorGeometry, floorMaterial);
floor.rotation.x = -Math.PI / 2; // Lay flat on XZ plane
scene.add(floor);
const raycaster = new THREE.Raycaster();
const mouse = new THREE.Vector2();
let points: THREE.Vector3[] = []; // i.e. wall endpoints
let tempLine: THREE.Line | null = null;
const walls: THREE.Line[] = [];
function getFloorIntersection(event: MouseEvent): THREE.Vector3 | null {
mouse.x = (event.clientX / window.innerWidth) * 2 - 1;
mouse.y = -(event.clientY / window.innerHeight) * 2 + 1;
raycaster.setFromCamera(mouse, camera);
const intersects = raycaster.intersectObject(floor);
if (intersects.length > 0) {
// Round to simplify coordinates (optional for cleaner drawing)
const point = intersects[0].point;
point.x = Math.round(point.x);
point.z = Math.round(point.z);
point.y = 0; // Ensure on floor plane
return point;
}
return null;
}
// Update temporary line preview
function onMouseMove(event: MouseEvent) {
const point = getFloorIntersection(event);
if (point && points.length > 0) {
// Remove old temp line if exists
if (tempLine) {
scene.remove(tempLine);
tempLine = null;
}
// Create new temp line from last point to current hover
const geometry = new THREE.BufferGeometry().setFromPoints([points[points.length - 1], point]);
const material = new THREE.LineBasicMaterial({ color: 0x0000ff }); // Blue for temp
tempLine = new THREE.Line(geometry, material);
scene.add(tempLine);
}
}
// Add a new point and draw permanent wall segment
function onMouseDown(event: MouseEvent) {
if (event.button !== 0) return; // Left click only
const point = getFloorIntersection(event);
if (point) {
points.push(point);
if (points.length > 1) {
// Draw permanent wall line from previous to current point
const geometry = new THREE.BufferGeometry().setFromPoints([points[points.length - 2], points[points.length - 1]]);
const material = new THREE.LineBasicMaterial({ color: 0xff0000 }); // Red for permanent
const wall = new THREE.Line(geometry, material);
scene.add(wall);
walls.push(wall);
}
// Remove temp line after click
if (tempLine) {
scene.remove(tempLine);
tempLine = null;
}
}
}
// Add event listeners
window.addEventListener('mousemove', onMouseMove);
window.addEventListener('mousedown', onMouseDown);
// Animation loop
function animate() {
requestAnimationFrame(animate);
renderer.render(scene, camera);
}
animate();
The above code snippet is a very basic 2D pen tool, and yet this information is enough to generate an entire room instance. For reference: not only does each line segment represent a wall (2D plane), but the set of accumulated points can also be used to auto-generate the room’s floor mesh, and likewise the ceiling mesh (the inverse of the floor mesh).
In order to view the planes representing the walls in 3D, one can transform each THREE.Line into a custom Wall class object, which contains both a line (for orthogonal 2D “floor plan” view) and a 2D inward-facing plane (for perspective 3D “room” view). To build this class:
class Wall extends THREE.Group {
constructor(length: number, height: number = 96, thickness: number = 4) {
super();
// 2D line for top view, along the x-axis
const lineGeometry = new THREE.BufferGeometry().setFromPoints([
new THREE.Vector3(0, 0, 0),
new THREE.Vector3(length, 0, 0),
]);
const lineMaterial = new THREE.LineBasicMaterial({ color: 0xff0000 });
const line = new THREE.Line(lineGeometry, lineMaterial);
this.add(line);
// 3D wall as a box for thickness
const wallGeometry = new THREE.BoxGeometry(length, height, thickness);
const wallMaterial = new THREE.MeshBasicMaterial({ color: 0xaaaaaa, side: THREE.DoubleSide });
const wall = new THREE.Mesh(wallGeometry, wallMaterial);
wall.position.set(length / 2, height / 2, 0);
this.add(wall);
}
}
We can now update the wall draw module to utilize this newly created Wall object:
// Update our variables
let tempWall: Wall | null = null;
const walls: Wall[] = [];
// Replace line creation in onMouseDown with
if (points.length > 1) {
const start = points[points.length - 2];
const end = points[points.length - 1];
const direction = end.clone().sub(start);
const length = direction.length();
const wall = new Wall(length);
wall.position.copy(start);
wall.rotation.y = Math.atan2(direction.z, direction.x); // Align along direction (assuming CCW for inward facing)
scene.add(wall);
walls.push(wall);
}
Upon adding the floor and ceiling meshes, we can further transform our wall module into a room generation module. To recap what we have just created: by adding walls one by one, we have given the user the ability to create full rooms with walls, floors, and ceilings—all of which can be adjusted later in the scene.
User dragging out the wall in 3D perspective camera-view.
Generating Cabinets with Procedural Modeling
Our cabinet-related logic can consist of countertops, base cabinets, and wall cabinets.
Rather than taking several minutes to add the cabinets on a case-by-case basis—for example, like with IKEA’s 3D kitchen builder—it’s possible to add all the cabinets at once via a single user action. One method to employ here is to allow the user to draw high-level cabinet line segments, in the same manner as the wall draw module.
In this module, each cabinet segment will transform into a linear row of base and wall cabinets, along with a parametrically generated countertop mesh on top of the base cabinets. As the user creates the segments, we can automatically populate this line segment with pre-made 3D cabinet meshes in meshing software like Blender. Ultimately, each cabinet’s width, depth, and height parameters will be fixed, while the width of the last cabinet can be dynamic to fill the remaining space. We use a cabinet filler piece mesh here—a regular plank, with its scale-X parameter stretched or compressed as needed.
Creating the Cabinet Line Segments
User can make a half-peninsula shape by dragging the cabinetry line segments alongside the walls, then in free-space.
Here we will construct a dedicated cabinet module, with the aforementioned cabinet line segment logic. This process is very similar to the wall drawing mechanism, where users can draw straight lines on the floor plane using mouse clicks to define both start and end points. Unlike walls, which can be represented by simple thin lines, cabinet line segments need to account for a standard depth of 24 inches to represent the base cabinets’ footprint. These segments do not require closing-polygon logic, as they can be standalone rows or L-shapes, as is common in most kitchen layouts.
We can further improve the user experience by incorporating snapping functionality, where the endpoints of a cabinet line segment automatically align to nearby wall endpoints or wall intersections, if within a certain threshold (e.g., 4 inches). This ensures cabinets fit snugly against walls without requiring manual precision. For simplicity, we’ll outline the snapping logic in code but focus on the core drawing functionality.
We can start by defining the CabinetSegment class. Like the walls, this should be its own class, as we will later add the auto-populating 3D cabinet models.
class CabinetSegment extends THREE.Group {
public length: number;
constructor(length: number, height: number = 96, depth: number = 24, color: number = 0xff0000) {
super();
this.length = length;
const geometry = new THREE.BoxGeometry(length, height, depth);
const material = new THREE.MeshBasicMaterial({ color, wireframe: true });
const box = new THREE.Mesh(geometry, material);
box.position.set(length / 2, height / 2, depth / 2); // Shift so depth spans 0 to depth (inward)
this.add(box);
}
}
Once we have the cabinet segment, we can use it in a manner very similar to the wall line segments:
let cabinetPoints: THREE.Vector3[] = [];
let tempCabinet: CabinetSegment | null = null;
const cabinetSegments: CabinetSegment[] = [];
const CABINET_DEPTH = 24; // everything in inches
const CABINET_SEGMENT_HEIGHT = 96; // i.e. both wall & base cabinets -> group should extend to ceiling
const SNAPPING_DISTANCE = 4;
function getSnappedPoint(point: THREE.Vector3): THREE.Vector3 {
// Simple snapping: check against existing wall points (wallPoints array from wall module)
for (const wallPoint of wallPoints) {
if (point.distanceTo(wallPoint) < SNAPPING_DISTANCE) return wallPoint;
}
return point;
}
// Update temporary cabinet preview
function onMouseMoveCabinet(event: MouseEvent) {
const point = getFloorIntersection(event);
if (point && cabinetPoints.length > 0) {
const snappedPoint = getSnappedPoint(point);
if (tempCabinet) {
scene.remove(tempCabinet);
tempCabinet = null;
}
const start = cabinetPoints[cabinetPoints.length - 1];
const direction = snappedPoint.clone().sub(start);
const length = direction.length();
if (length > 0) {
tempCabinet = new CabinetSegment(length, CABINET_SEGMENT_HEIGHT, CABINET_DEPTH, 0x0000ff); // Blue for temp
tempCabinet.position.copy(start);
tempCabinet.rotation.y = Math.atan2(direction.z, direction.x);
scene.add(tempCabinet);
}
}
}
// Add a new point and draw permanent cabinet segment
function onMouseDownCabinet(event: MouseEvent) {
if (event.button !== 0) return;
const point = getFloorIntersection(event);
if (point) {
const snappedPoint = getSnappedPoint(point);
cabinetPoints.push(snappedPoint);
if (cabinetPoints.length > 1) {
const start = cabinetPoints[cabinetPoints.length - 2];
const end = cabinetPoints[cabinetPoints.length - 1];
const direction = end.clone().sub(start);
const length = direction.length();
if (length > 0) {
const segment = new CabinetSegment(length, CABINET_SEGMENT_HEIGHT, CABINET_DEPTH, 0xff0000); // Red for permanent
segment.position.copy(start);
segment.rotation.y = Math.atan2(direction.z, direction.x);
scene.add(segment);
cabinetSegments.push(segment);
}
}
if (tempCabinet) {
scene.remove(tempCabinet);
tempCabinet = null;
}
}
}
// Add separate event listeners for cabinet mode (e.g., toggled via UI button)
window.addEventListener('mousemove', onMouseMoveCabinet);
window.addEventListener('mousedown', onMouseDownCabinet);
Auto-Populating the Line Segments with Live Cabinet Models
Here we fill 2 line-segments with 3D cabinet models (base & wall), and countertop meshes.
